Set up Outline Wiki with local object storage and OIDC integration

Kovasky Buezo | May 7, 2024 min read

edited on: May 17, 2024

Set up Outline Wiki with local object storage and OIDC integration

Intro

I started using Notion’s free tier as a knowledge bank for a side project. It’s measley 1000 blocks were capped quickly and searching for an alternative lead to Outline. Outline is 100% free, selfhostable, and has a very similar featureset.

Most of the guides out there configure Outline with an S3 store for object storage, but I do not really have a need for it. Also, I wanted to integrate Outline with Authelia for integration with my Active Directory server as well as Fail2Ban.

Docker Compose

After some trial and error, this was the resuting compose file that spins up Outline with OIDC and local object storage.

version: "3.1"
services:
  redis:
    image: redis
    restart: unless-stopped
    container_name: redis
    networks:
      - internal

  postgres:
    image: postgres:latest
    restart: unless-stopped
    container_name: postgres
    environment:
      - POSTGRES_PASSWORD=${POSTGRES_PASSWORD}
      - POSTGRES_USER=outline
      - POSTGRES_DB=outline
    networks:
      - internal
    volumes:
      - db:/var/lib/postgresql/data

  outline:
    image: outlinewiki/outline
    user: root
    restart: unless-stopped
    container_name: outline
    command: sh -c "yarn start --env=production-ssl-disabled"
    depends_on:
      - postgres
      - redis
    environment:
      - PGSSLMODE=disable
      - SECRET_KEY=${SECRET_KEY}
      - UTILS_SECRET=${UTILS_SECRET}
      - DATABASE_URL=postgres://outline:${POSTGRES_PASSWORD}@postgres:5432/outline
      - REDIS_URL=redis://redis:6379
      - URL=${WIKI_URL}
      - PORT=3000
      - FORCE_HTTPS=false
      - OIDC_CLIENT_ID=outline
      - OIDC_CLIENT_SECRET=${OIDC_SECRET}
      - OIDC_AUTH_URI=${AUTH_URI}
      - OIDC_TOKEN_URI=${AUTH_TOKEN}
      - OIDC_USERINFO_URI=${AUTH_USERINFO}
      - OIDC_USERNAME_CLAIM=preferred_username
      - OIDC_DISPLAY_NAME=Authelia
      - OIDC_SCOPES=openid email groups profile
      - FILE_STORAGE=local
      - FILE_STORAGE_UPLOAD_MAX_SIZE=26214400
      - FILE_STORAGE_IMPORT_MAX_SIZE=
      - FILE_STORAGE_WORKSPACE_IMPORT_MAX_SIZE=
      - SMTP_HOST=$SMTP_HOST
      - SMTP_PORT=$SMTP_PORT
      - SMTP_USERNAME=$SMTP_USER
      - SMTP_PASSWORD=$SMTP_PASSWORD
      - SMTP_FROM_EMAIL=$SMTP_FROM
      - SMTP_TLS_CIPHERS=TLSv1.2
      - SMTP_SECURE=false
    volumes:
      - data:/var/lib/outline/data
    ports:
      - 10300:3000
    networks:
      - internal

networks:
  internal:

volumes:
  db:
    driver: local
  data:
    driver: local

Here is how you populate the variables:

  • ${SECRET_KEY}, can be any random string (the longer the better)

  • ${UTILS_SECRET}, can be any random string (the longer the better)

  • ${POSTGRES_PASSWORD}, can be any random string (the longer the better)

  • ${WIKI_URL}, where outline will be accessed (like a reverse proxy address)

  • ${OIDC_SECRET}, a random jwt token

  • ${OIDC_AUTH_URI}=${AUTH_URI}, https://<authelia_domain>/api/oidc/authorization

  • ${OIDC_TOKEN_URI}=${AUTH_TOKEN}, https://<authelia_domain>/api/oidc/token

  • ${OIDC_USERINFO_URI}=https://<authelia_domain>/api/oidc/userinfo

Authelia configuration

This is how the configuration.yml for Authelia should look like:

identity_providers:
  oidc:
    issuer_private_key: |
      <private_key>
    clients:
    - id: outline
      description: Outline Wiki
      secret: '$plaintext$<OIDC_SECRET>'
      public: false
      authorization_policy: two_factor
      redirect_uris:
        - https://<WIKI_URL>/auth/oidc.callback
      scopes:
        - openid
        - profile
        - email
        - groups
      response_types:
        - code
      grant_types:
        - refresh_token
        - authorization_code
      response_modes:
        - form_post
        - query
        - fragment
      userinfo_signing_algorithm: none
      token_endpoint_auth_method: client_secret_post
      consent_mode: implicit

Here is how you populate the variables:

  • ${WIKI_URL}, where outline will be accessed (like a reverse proxy address)

  • ${OIDC_SECRET}, jwt token used in the docker compose file

  • private_key, please visit the authelia guide located here

Done!

Once set up with these config settings, outline should be up and running. You can take a look at this compose file, as well as others here.
